Tsurumi Avant Premium Grade Submersible Sewage Pump

Tsurumi Avant Premium Grade Submersible Sewage Pump

The Tsurumi Avant MQ-series is the premium grade of submersible sewage pumps by Tsurumi Pump equipped with an IE3 premium efficiency motor. These pumps offer 5 types of impellers (Open Channel, Chopper, Vortex, Grinder and High Head) and super wide ranges of specifications featuring 50 to 600 mm discharge bore diameters and 1.8 to 355 kW motor output specifications.

The MQ-series of the TSURUMI AVANT brand adds an IE3 premium efficiency motor to the premium grade of submersible sewage pumps that Tsurumi makes. With this new series, overall efficiency and energy-savings have been taken to new heights by pursuing greater efficiency in both the pump and motor.

Moreover, to ensure users get what they are looking for, the MQ-series offers 5 types of impellers (Open Channel, Chopper, Vortex, Grinder and High Head) and super wide ranges of specifications featuring 50 to 500 mm discharge bore diameters and 1.1 to 355 kW motor output specifications. Plus, pump installation can be chosen between a WET version that submerges the pump in water or a DRY version that installs the pump indoors or outside the tank using the original closed loop cooling system with internal recirculation.

Furthermore, MQ-series pumps accordance with IECEx explosion-proof specifications, and can be used in dry pits and other sites.

Characteristics

  • Cast iron structure (stainless steel on request)
  • Class H electric motor from 1.1 kW to 355 kW in efficiency class IE3
  • 50 Hz and 60 Hz versions
  • Thermal protection devices incorporated in stator
  • Long life bearings (100,000 hours)
  • AISI 431 drive shaft (AISI 329 on request)
  • Leakage detection system in seal chamber (standard) and motor (on request)
  • Double silicon carbide mechanical seals with Oil Lifter in large oil chamber
  • Discharge from DN50 to DN500
  • Large free passage declared for every model
  • WET or DRY version available
  • Original closed loop cooling system with internal recirculation
  • Operating temperature up to 40°C (up to 60° on request)
  • Explosion-proof available (Designed in accordance with IECEx)

Complete the following form, so we can help you with the best solution for your application. We’re at your service.

Thick sludge has to be pumped out of a cement factory

Thick sludge has to be pumped out of a cement factory

Thick sludge has to be pumped out of a cement factory in northwestern Turkey. Conventional #wastewater pumps fail here because of the abrasive medium. However, the sludge pumps of the #Tsurumi KRS series are completely different. Extremely robust submersible pumps made of heavy-duty cast iron, driven by a 4-pole motor.

Settled materials are mixed into a pumpable suspension by the built-in agitator. The other wearing parts such as the impeller and suction plate are also made of high-chrome cast iron to increase durability. The design with upward side discharge ensures efficient engine cooling even when the engine is operated in air.

The specifications of the KRS series can be found here:

https://lnkd.in/dNvXkU6

#stronger4longer

Cast Iron Pumps for Mining, Aggregate and Construction – KRS Series by Tsurumi Pump

Cast Iron Pumps for Mining, Aggregate and Construction – KRS Series by Tsurumi Pump

KRS-series Submersible heavy-duty general-purpose drainage pumps are designed and built to handling high volume pumping jobs. These pumps are offering 80 to 250mm discharge bore, and 2.2 to 22kW motor output.Built For Work® KRS Series Catalog (PDF)
Tsurumi Pumps for Well Dewatering (PDF)

Tsurumi Pump

As a pioneer in the submersible pumps, Tsurumi Pump is contributing to the people all over the world by supplying the products that always support people’s lives such as submersible pumps for wastewater and construction, centrifugal pumps, vacuum pumps, and water treatment equipment, etc. and also by offering technologies that control and protect water.
First In-person Team Meeting After Lockdown at Tsurumi

First In-person Team Meeting After Lockdown at Tsurumi

Tsurumi America Inc. (Tsurumi) employees in Chicago physically met for the first time since the beginning of the COVID-19 outbreak in March. Wearing masks and keeping 6 ft of distance in the company’s spacious warehouse in Glendale Heights, Illinois, coworkers from different departments shared their experience of working from home in the last four months and how things have changed in their routines during the lockdown. Attendees participated in a presentation on innovation and discussed how to promote it at work.

Tsurumi_News-Tsurumi-America-holds-first-in-person-team-meeting-after-lockdown-3_700x500

To ensure a safe environment at the meeting on Friday, Tsurumi followed the guidelines from the Illinois Department of Public Health, which included providing hand hygiene at the entrance of the warehouse and requesting employees who were sick to remain at home. The initial plan was to hold the meeting outdoors, but due to the rain the company moved it to the warehouse.

“It was not an ordinary work meeting,” said Glenn Wieczorek, managing director, Tsurumi. “Some employees have reached out to us saying that they really missed their coworkers and that they would like to get together, so as some workplaces are reopening we thought about giving them an opportunity to meet again, see how each other are doing, while making sure that everyone was safe.”

Wieczorek explained that Tsurumi is not requesting its personnel to go back to the office, and the majority are still working remotely. Over the last four months, the manufacturer has registered the same high productivity level from before the COVID-19 outbreak.

“We’ve been successful and effective on our approach. Our North American customers are happy and our team is staying safe, so there is no rush to go back to the office,” Wieczorek said. “We can always reevaluate things one, two months from now, if that’s the case. But I believe some changes have come to stay and working remotely will probably become the new normal.



Source: Tsurumi America Inc. holds first in-person team meeting after lockdown

Tsurumi Pump SLIMLINE Dewatering Pumps

Tsurumi Pump SLIMLINE Dewatering Pumps

LH/LHW SERIES Extreme High head pumping at high volumes

These slimline dewatering pumps are capable of extremely high head pumping. The LH series pumps are typically used in deep wells, mines, and quarries, or just about any other application where long distance water transfer is required.

Slimline Dewatering Pumps

Tsurumi Submersible Pump – Extended life with patented oil lifter technology

Tsurumi Submersible Pump – Extended life with patented oil lifter technology

Pumps without an oil lifter do not offer enough cooling and lubrication of the upper mechanical seal. This will quickly result in a failure of the mechanical seal. Tsurumi invented the oil lifter and owns patent. The oil lifter will ensure cooling and lubrication of the upper mechanical seal – in all positions and applications, even in dry running conditions. Horizontal as well as vertical operations are possible.
